Solid 40.5kV Expoxy Resin Conjoined Insulator For Switchgear High Voltage

China Solid 40.5kV Expoxy Resin Conjoined Insulator For Switchgear High Voltage supplier
Solid 40.5kV Expoxy Resin Conjoined Insulator For Switchgear High Voltage supplier Solid 40.5kV Expoxy Resin Conjoined Insulator For Switchgear High Voltage supplier Solid 40.5kV Expoxy Resin Conjoined Insulator For Switchgear High Voltage supplier Solid 40.5kV Expoxy Resin Conjoined Insulator For Switchgear High Voltage supplier

Large Image :  Solid 40.5kV Expoxy Resin Conjoined Insulator For Switchgear High Voltage

Product Details:

Place of Origin: WENZHOU
Brand Name: QIUPU
Certification: IEC
Model Number: ZNZX1-40.5kV

Payment & Shipping Terms:

Minimum Order Quantity: 60 PCS
Packaging Details: Cartons
Delivery Time: 7 Days
Payment Terms: T/T, Western Union
Supply Ability: 50000 PCS/Month
Contact Now
Detailed Product Description
Material: Epoxy Resin Color: Red/Brown
Rate Voltage: 40.5kV Creepage Distance: 810mm
Flexural Strength: 8 KN Current: 630A-1250A

ZNZX1-40.5kV Expoxy Resin Insulator with Disconnecting Switch





We are specialty on epoxy resin medium voltage and high voltage components, such as 10KV, 24 KV and 40.5KV Circuit Breaker , Load breaker switch , Disconnecting Switch , Epoxy resin switchgear bushing , contactor box , insulators and transformer . 630A, 1250 A ,2500A , 3150A and 4000A contact box , club contact , fix contact, arm contact and jaw contact . 630A and 1250A VS1 circuit breaker . 630A and 1250A ZN85-40.5 circuit breaker . 12KV and 24KV earth switch. KYN28A-12 and KYN61 high voltage switchgear components .



The pressure molding machine of epoxy resin adopts PTL C, which is more humane, and has the following characteristics in comparison with the domestic products: The 10-year-old model has been lengthened from 3.2 meters to 3.4 meters at the moment, optimizing the space available for monopolists.2, 3 kinds of whole machine can be vertical, horizontal tilt. After opening the die, close the end of the motor press twist, monopolist can enter the machine to take products, liquidation mold. Middle cabinet, all known as metal armor in the case of a shift switch equipment.



It is a high voltage distribution unit with a maximum operating voltage of 3.6 / 7.2 / 12kV and is an indoor distribution unit of a three-phase AC 50 Hz single bus segment system or a double bus segment system. It is used to receive and match the network electricity of 3.6-12kV, and to control, protect, monitor and measure the electric circuit. Medium type switchgear is mainly used for power plant, small and medium power generator, power substation of power system, power supply, power distribution of industrial and mining enterprises, and starting of large high voltage motor.





Item Technical data
Rated voltage (KV)         40.5
Rated frequency(Hz) 50
Insulator(capacity) insulating Frequency withstand voltage 5 min (KV)         100
Frequency withstand voltage 1 min (V) 2000
Lighting impulse withstand voltage (KV)         185
Local discharge (pc) ≤10
Dispute bend (N) ≥10000
Creepage Distance 800mm

       Solid 40.5kV Expoxy Resin Conjoined Insulator For Switchgear High Voltage
