DXN-T Indoor High Voltage Indicators Electric Display Device for Protection

Place of Origin WENZHOU
Brand Name QIUPU
Certification IEC
Model Number DXN-T
Minimum Order Quantity 100 PCS
Packaging Details Cartons
Delivery Time 5 Days
Payment Terms T/T, Western Union
Supply Ability 5000PCS/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Material Plastic Rated Voltage 3.6kV-40.5kV
Work Voltage AC/DC110V/220V Rated Current 16A
Color Black
High Light

live line indicator


voltage indicator device

Leave a Message
Product Description

DXN-T Indoor High Voltage Indicator with Switchgear equipment




1. The dual display of LCD and long-life flash electric inspection plug-in is suitable for the operation environment of all kinds of light. The special electric test plug-in constitutes the unique independent electric test function, which improves the reliability of the device as the basis of electric test. The device adopts phase-splitting detection digital superposition locking control technology, which can ensure that the locking voltage is constant and stable when the system lacks the equivalent abnormal operation. Compulsory electrical locking function, can be reliable locking ground switch(switch cabinet door). The application of the new high voltage electric display and electric inspection device can effectively prevent the accident caused by the electric gap or the electric connected ground switch.



2. The old type of high-voltage electric display device with mandatory electrical latching, which is too simple in principle, consists of half wave rectifying and directly combining the signals from the A, B and C phase sensors to control the latching circuit. In this way, when the system has an anomaly of single phase grounding or absence phase, the drift of the locked-in control voltage can lead to the accident of the electrically connected grounding switch.


Item Technical data
Rated voltage (KV)   7.2 12 24 40.5
Rated frequency(Hz) 50
Insulator(capacity) insulating Frequency withstand voltage 5 min (KV) 25 32 42 68 100
Frequency withstand voltage 1 min (V) 2000
Lighting impulse withstand voltage (KV)   60 75 125 185
Rated Current 16A


      DXN-T Indoor High Voltage Indicators Electric Display Device for Protection 0
