Aluminum Foil PVC APCMS Shielded Magic Sleeve Shield Interference Source Effectively

Product application

The shielded zipper sleeve (ZPCA) is made of aluminum foil PVC, tinned copper braided tape, and plastic zipper. This product has high sealing, flame retardant properties. Products are widely used in semiconductor equipment, medical equipment, laser equipment and other industries with high shielding requirements, playing a role in preventing electromagnetic wave interference.



Material: Aluminum foil +PVC+POM+Tlnned wire

Thickness: 0.22mm (Aluminum foil PVC)

Color: Black

Usage: Use the JP-TUBING tool

Functions: Anti-electromagnetic wave interference, high shielding performance, high sealing performance

Available Temperature: -15X^-+60^C



1,PVC     2,Shielding material    3, Con^x zipper     4,Concag zipper Tin    5,copper wire





specification
Model	width(mm)	beam diameter(mm)	length	packaging method
APCMS-15	95	15
APCMS-20	110	20
APCMS-25	125	25
APCMS-30	143	30
APCMS-40	174	40	25M	Paper box
APCMS-50	205	50
APCMS-70	262	70
APCMS-100	358	100



How to use shielding sleeve

Electromagnetic signal aluminum foil shielding sleeve is a new type of shielding sleeve produced by our company according to the drawings of Japanese customers, which has better shielding performance than the traditional tinned copper shielding sleeve and shielding mesh type shielding sleeve on the market.

The aluminum foil shielding sleeve adopts Velcro or buckle structure, and the open structure is more conducive to customer packaging wiring harness for maintenance and reuse. Because our company provides such products are 25 meters / box, so customers need to cut to the specified length after purchase, and then package at the location where the source of electromagnetic signal transmission is required.

However, in order to ensure the correctness of the installation, the aluminum foil buckle casing manufacturer recommends that you can first test whether other places are still affected by the electromagnetic signal of the emitting source after installation.

Wenzhou Qiupu Electric Co., Ltd. was founded in 2006, Specializing in the development and production of cable protection and electromagnetic shielding. At present, the products are shielded button casing, shielded adhesive casing, shielded zipper casing, high temperature resistant casing, acid and alkali proof casing, anti-static casing, wear-resistant casing, industrial robot casing, button casing, adhesive casing, zipper casing and self-winding casing. For military industry, semiconductor equipment, high-speed rail, power equipment, automation control, medical equipment, welding equipment, elevator and other industries to provide high-quality cable protection and electromagnetic shielding solutions. Products have passed ISO9001, ROHS, VTM-0, REACH and other certifications.
